•Durable construction using heavy-duty metal, ideal for demanding environments in medical, industrial, and military applications
•Meets stringent flammability standards, ensuring safety across various sectors
•Accommodates two U.2/U.3 PCIe 5.0 SSDs, up to 15mm in height, and one slim optical disk drive (12.7mm)
•Supports fast PCIe 5.0, enabling speeds up to 128Gbps for quick data transfer
•Features a removable caddy system for U.2/U.3 and slim optical disk drives, simplifying maintenance

metal_tray_enclosures,nvme_enclosures,tool-less_tray_enclosures,tool-less_tray_enclosures

•Fits 2x E3.S NVMe SSDs up to 7.5mm height
•Installs into standardized external 3.5” device bay (floppy bay)
•Uses a MCIO 8i connector, supporting PCIe 5.0 x4 with transfer speeds up to 128GB/s
•Supports hot-plug functionality for E3.S SSD (dependent on host environment)
•Comes equipped with a 25mm fan, which can be replaced without disassembling the entire unit
•Ruggedized full-metal enclosure and drive trays

•Supports 1 x 7.5mm height E3.S NVMe SSD
•Compatible with PCIe x4/ x8 /x16 Slot
•Supports PCIe Gen 5.0 x 4 speed up to 128Gbps
•Supports drive hot-plug without requiring the system to be powered down
•Active Power Technology (APT) – drive activity LED only powers up if there is a drive installed in the bay
•Optional 4-pin drive activity signal output - allows for easy transfer of the drive activity signal to the front of the computer case

•Fits 1x 5.25" optical drive bay of a computer case or rackmount
•Accommodates 4x 2.5" U.2/U.3 NVMe SSDs, up to 15mm in height
•Utilizes 2x MCIO 8i connectors, supports PCIe 5.0 x4 with up to 128Gbps transfer speeds
•Removable drive caddy with retractable handle for easy installation/removal of 4 drives at once
•Equipped with dual 40x40x20mm fans; fans can be replaced without disassembling the unit
•Supports hot-plug functionality for U.2/U.3 NVMe SSDs (host environment must support hot-plug)

•World’s first Universal Backplane Management (UBM) drive mobile rack enclosure
•Supports 4x 2.5” SAS/SATA/U.3 NVMe SSD/HDD (Tri-mode adapter is required to access SAS, SATA, and U.3 NVMe through the same drive bay)
•Supports SAS 4.0 (up to 22.5Gbps), SATA 3.0 (up to 6Gbps), and NVMe Gen 4 (up to 64Gbps)
•Installs into any standard external 5.25” optical drive bay
•Uses 2x SlimSAS 8i (SFF-8654) rear connectors
•Ruggedized full-metal enclosure meeting flammability requirements

•World’s first Universal Backplane Management (UBM) drive mobile rack enclosure
•Supports 4x 2.5” SAS/SATA/NVMe (U.2/U.3) SSD/HDD
•Supports SAS 4.0 (up to 22.5Gbps), SATA 3.0 (up to 6Gbps), and NVMe Gen 4 (up to 64Gbps)
•Installs into any standard external 5.25” optical drive bay
•Uses 2x SlimSAS 8i (SFF-8654) rear connectors
•Ruggedized full-metal enclosure meeting flammability requirements

•Fits 2x E1.S NVMe SSD, up to 9.5mm thickness.
•Uses PCIe 1.0/2.0/3.0/4.0/5.0 x8 or x16 slot.
•Supports hot-swap/hot-plug E1.S NVMe SSD.
•Removable drive tray with tool-less drive installation for easy drive maintenance.
•The eagle-hook lock system keeps the drive secured in the enclosure.
•Equipped with a 50mm blower fan for maximum thermal performance.

•Fits in Standard 5.25" Drive Bay.
•Supports 8 x E1.S (EDSFF) NVMe SSDs (5.9/8.01mm height) or 8 x M.2 NVMe SSD (2230/2242/2260/2280/22110).
•Uses 4 x SlimSAS 8i (SFF-8654) port supports PCIe 4.0 x4 of up to 64Gbps data transfer rates.
•Ability to mix and match E1.S and M.2 NVMe SSDs in a single enclosure.
•Supports tool-less drive installation for both E1.S and M.2 NVMe SSDs.
•Equipped with dual 40mm detachable fans for superior cooling performance.

•Fits 4 x E1.S (EDSFF) NVMe SSD (5.9mm/8.01mm/9.5mm/15mm) or
4x M.2 NVMe SSD (2230/2242/2260/2280/22110) in a 5.25" external drive bay.
•Uses 2 x MCIO 8i (SFF-TA-1016 8i) port supports PCIe 5.0x4 of up to 128Gbps data transfer rates.
•Full-metal housing and drive tray provide excellent durability and robustness - ideal for the enterprise-level data storage environment.
•Equipped with dual 40mm detachable fans for superior cooling performance.
•The Eagle-hook tray latch design securely holds the drive trays within the enclosure.
•Anti-Vibration (AVT) technology provides a stable and safe operating environment for SSDs.

•Supports 1 x U.2 NVMe SSD up to 9.5mm height
•Use 1 x PCIe 4.0 x4 interface and supports installation into PCIe 1.0/2.0/3.0/4.0 x4, x8, and x16 slots
•Support PCIe 4.0 x4 with transfer rates up to 64Gbps
•Removable drive tray with tool-less drive installation design for easy drive maintenance
•Eagle-hook lock system keeps the drive secure in the enclosure
•EMI grounding - protects hard drives from electrical damage

•Fits 1x EDSFF E1.S SSD with a maximum drive thickness of 5.9mm
•Use 1x PCIe 4.0 x4 interface, also supports installation into PCIe 1.0/2.0/3.0/4.0 x4, x8, and x16 slots
•Support PCIe 4.0 x4 with transfer rates up to 64Gbps
•Includes half-height and full-height PCIe brackets
•Removable drive tray with tool-less drive installation design for easy drive maintenance
•Low profile design allows for multiple bays to be installed side-by-side in a modular design

•Fits 8 x 2.5" U.2 NVMe SSDs into 2 x 5.25" external drive bay
•Removable drive tray for easy drive installation and removals
•Uses 4 x MCIO ports to connect (NVMe host required)
•MCIO connector pinout supports SFF-TA-1016 specification
•Supports the full PCIe 5.0 x4 bandwidth specifications of 128Gbps per drive bay
•Ruggedized full metal housing and tray that meets flammability requirement
